UHF Point-To-Point Commercial Grade Yagi Antenna – 406-512 MHz

Item Code: 00017
Model: 460-7


Advantages

  • A rugged, high gain design with a clean radiation pattern allows these antennas to meet the performance requirements of many applications. An excellent choice for low cost RF security monitoring and other localized UHF installations


Features

  • “EverSealed” feed system which insures against system failures due to moisture
  • Square boom construction for greater strength and solid aluminum rod elements
  • Flexible feedline interface with custom cable lengths available for easier, reliable installation
  • No field tuning required.


Electrical Specifications

Frequency Range 450-470
Gain, dBd 10
3 dB Beamwidth E/H Planes 48/57
Power 100


Mechanical Specifications

Number of Elements 7
Wind Rating 125/200

Quick Guide

Model# Frequency Gain Beamwidth
410-6 406-420 9 53/67
420-10 406-430 11 40/45
430-6 420-450 9 53/67
460-10 450-470 11 40/45
460-2 450-470 3.5 71/145
460-3 450-470 3.5 67/116
460-6 450-470 9 50/62
460-7 450-470 10 48/57
480-10 470-490 11 40/45
480-6 470-490 9 50/62
500-10 590-512 11 40/45
500-6 590-512 9 50/62
